Pantile Roof Hook AV KP
SDHS1408
Product Description
Universal stainless steel roof hook with pre-fixed clamping plate for common pantiles. Low material-profile for better fit between roof tiles, large base plate expands possible mounting area.
Technical Properties
Mounting System Pitched Roof, Pantile Roofing
Material Stainless Steel
FinishSandblasted
Adjustableno
Sales Unit1
Dimensions
Base Plate: 180 x 80 x 4 mm | Total Height: 150 mm | Height under Bracket: 40 mm | Bracket: 40 x 6 mm | Bracket Height: 111 mm | Bracket Length: 134 mm
DesignUniversal stainless steel roof hook, front attachment of the mounting rail with pre-assembled clamping plate. The slotted hole allows a height adjustment of the mounting rail of 30 mm.
